Lighter power. Bigger capability.

The Marin Bikes Rift Zone EL 2 builds on the Electric Light platform with higher-end components for riders who want maximum trail performance without the bulk of a full-power eMTB. It takes everything that makes the Rift Zone EL playful and responsive, then turns the dial up on suspension, drivetrain, and braking control.

Powered by Bosch’s lightweight Performance Line SX motor and CompactTube internal battery, the Rift Zone EL 2 delivers smooth, natural assistance that blends seamlessly with your pedaling. With Fox Performance suspension front and rear, SRAM’s GX-level drivetrain, and Code Bronze 4-piston brakes, the EL 2 is built for aggressive trail riding, steep descents, and riders who demand more from a lightweight eMTB.

Key Features

• Bosch Performance Line SX Drive System
Lightweight 600W motor with 55Nm of torque delivers responsive, natural-feeling assistance on climbs and rolling terrain.

• Advanced Fox Performance Suspension
150mm Fox 36 Performance fork paired with a Fox Float X rear shock for improved traction, control, and confidence on demanding trails.

• Trail-Ready Alloy Frame
Series 4 Alloy Lightweight E frame with 140mm MultiTrac rear suspension, integrated battery, and modern trail geometry.

• SRAM GX Eagle Drivetrain
Wide-range 12-speed drivetrain provides crisp shifting and reliable performance under eMTB loads.

• Powerful Code Bronze Braking
SRAM Code Bronze 4-piston brakes with HS2 rotors deliver consistent stopping power on steep, technical descents.

• Aggressive 29” Wheel & Tire Setup
Wide rims and Maxxis Minion DHF / Forekaster tire combination offer grip, stability, and tubeless-ready performance.

Technical Specifications

• App: Bosch eBike Flow App
• Range: 15–55 miles / 25–90km
• Display: Bosch BRC3100 Systems Controller
• Switch: Bosch BRC3300 Bluetooth Remote (22.2mm Clamp)
• Battery: Bosch 400Wh Internal (Optional PowerMore 250Wh external battery using PowerMore 150mm cable EB12.120.036)
• Motor: Bosch Performance Line SX, 600W, 55Nm

• Frame: Series 4 Alloy Lightweight E, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle
• Front Suspension: Fox 36 Performance, 150mm Travel, 29”, 44mm Offset
• Rear Suspension: Fox Float X Performance, EVOL Air Spring, Custom Tune

• Rims: Marin Aluminum Double Wall, 29”, 32mm Inner Width, Tubeless Compatible
• Hub Front: Formula DC-711, 110×15, 6-Bolt
• Hub Rear: Formula DCL-3482, 148×12, XD Driver, 6-Bolt
• Spokes: 14g Black Stainless Steel

• Tires:
Front – Maxxis Minion DHF, 29×2.5” EXO+ MAXXGRIP
Rear – Maxxis Forekaster, 29×2.4” EXO+ MAXX TERRA

• Chainguide: ethirteen eSpec Chainguide
• Derailleur: SRAM Eagle 90
• Shifter: SRAM Eagle 90 MMX, Single Click
• Crankset: ethirteen espec Plus, 160mm, 34T
• Chain: SRAM GX T-Type
• Cassette: SRAM XG-1275 Eagle, 10–52T

• Brakes: SRAM Code Bronze 4-Piston Hydraulic Disc
• Rotors: SRAM HS2, 200mm Front / Rear

• Handlebar: Marin Trail Alloy, 800mm, 20mm Rise
• Stem: Marin CNC Alloy, 35mm
• Grips: Marin Grizzly Lock-On
• Headset: FSA Custom, Adjustable HTA

• Seatpost: TranzX Dropper, 34.9mm (S 150mm / M-L 170mm / XL 200mm)
• Saddle: Marin Speed Concept
• Pedals: Marin MTB Plastic

Designed for trail riders who want premium suspension, powerful braking, and a lightweight eMTB that rides like a true trail bike.
