Marin Bikes | 2025 Team Marin 2

📏Size Guide

Race-focused speed meets modern trail capability in a lightweight carbon-ready XC hardtail platform.

The Marin Team Marin 2 29 is a premium XC trail hardtail designed for riders who want lightweight efficiency, sharp handling, and high-performance components for aggressive cross-country riding and fast trail sessions. Built around Marin’s superlight Series 4 aluminum frame, the Team Marin 2 combines progressive geometry with race-ready responsiveness for riders who demand speed without sacrificing control.

Equipped with a Fox 34 StepCast Performance fork, Shimano XT 12-speed drivetrain, tubeless-ready 29” wheels, and modern XC geometry, the Team Marin 2 is built for fast climbs, technical descents, marathon rides, and competitive trail riding.

Key Features

• Series 4 Superlight Aluminum Frame
Lightweight and responsive frame with internal routing and boost thru-axle spacing for precise handling and efficient power transfer.

• Fox 34 StepCast Performance Fork
120mm air suspension fork delivers lightweight XC performance with excellent small-bump sensitivity and trail control.

• 29” Wheel Platform
Large wheels improve rollover capability, momentum, traction, and stability on technical terrain.

• Shimano XT 1x12-Speed Drivetrain
High-performance shifting with wide-range gearing for steep climbs and fast-paced XC riding.

• Modern XC Trail Geometry
Balanced geometry provides confident descending while maintaining fast and efficient climbing characteristics.

• Dropper Post Equipped
Integrated TranzX dropper post improves descending control and technical riding confidence.

• Tubeless-Ready XC Wheelset
Wide internal rims paired with Maxxis Rekon Race tires maximize speed, grip, and efficiency.

Technical Specifications

• Category
XC Trail MTB Hardtail

• Discipline
MTB

• Frame
Series 4 6061 Aluminum, 148x12mm Boost Thru-Axle, Internal Routing

• Fork
Fox 34 StepCast Performance, 120mm Travel, Air Spring

• Bottom Bracket
FSA MegaExo 73mm BSA

• Headset
FSA No 42ACB, 1 1/8" x 1 1/2”

• Rear Derailleur
Shimano XT RDM8100 12-Speed

• Front Derailleur
N/A

• Shifters
Shimano SLX SLM7100 12-Speed

• Crankset
FSA Grid Modular 1x, 32T Direct Mount Chainring

• Cassette
SunRace 12-Speed, 11-51T

• Chain
KMC X12

• Brakes
Shimano Deore BR-MT4100 Hydraulic Disc Brakes

• Brake Rotors
180mm

• Wheelset
Marin Aluminum Double Wall, 29mm Inner Width, Tubeless Compatible

• Front Hub
Shimano 110x15mm, 32H

• Rear Hub
Forged Aluminum, 148x12mm, 32H

• Tires
Maxxis Rekon Race 29x2.35", Folding Bead, Tubeless Ready

• Handlebar
Marin Mini-Riser Alloy, 780mm Width

• Stem
Marin 3D Forged Alloy, 35mm

• Seatpost
TranzX Dropper Post, Size S = 125mm Travel, MD-XL = 150mm Travel

• Saddle
Marin Speed Concept

• Pedals
Nylon Platform

• Color Options
Dark Green / Gold (#1F4D3A)

Geometry

Suitable for XC racing, marathon riding, technical singletrack, trail riding, and fast all-around MTB use.
