Marin Bikes | 2022 DSX FS (Full Suspension)

Built to blur the line between urban speed and trail capability.

The Marin DSX FS is an adventure-oriented flat bar bike designed for riders who want the efficiency of a road bike, the confidence of a mountain bike, and the comfort to handle rough pavement, gravel paths, and mixed terrain with ease.

Built around Marin’s Series 3 DSX aluminum platform, the 2022 DSX FS combines progressive geometry, a lightweight air suspension fork, wide 700x45c tires, and a Shimano 1x12 drivetrain to create a highly versatile all-road machine. Unlike traditional hybrids that feel nervous or under-equipped off-road, the DSX FS delivers real capability for commuting, gravel riding, fitness riding, and light trail exploration.

Key Features

• Suspension-Adjusted Adventure Geometry
Progressive geometry delivers stable handling and confidence across pavement, gravel, and mixed terrain riding.

• SR Suntour Air Suspension Fork
60mm air suspension fork improves comfort and control while maintaining efficient everyday riding performance.

• Shimano 1x12-Speed Drivetrain
Wide-range Shimano drivetrain provides crisp shifting and excellent climbing capability across varied terrain.

• Flat Mount Hydraulic Disc Brakes
Shimano hydraulic disc brakes deliver strong braking power and improved modulation in all weather conditions.

• Wide Tire Adventure Platform
700x45c WTB Riddler tires improve grip, comfort, and versatility for commuting and gravel riding alike.

Technical Specifications

• Category
Adventure Road Bike

• Discipline
Gravel / Urban

• Frame
Series 3 DSX, Suspension Adjusted Geometry, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle

• Fork
SR Suntour GVX LOR Suspension Fork, 60mm Travel, Air Spring, Rebound Adjust, Lockout, Integrated Fender Mounts

• Travel
60mm

• Spring Type
Air

• Drivetrain
Shimano 1x12-Speed

• Rear Derailleur
Shimano SLX 12-Speed

• Shifters
Shimano Deore 12-Speed

• Crankset
Forged Aluminum Crankset with 42T Steel Narrow-Wide Chainring

• Cassette
Shimano Deore 12-Speed, 10-51T

• Chain
KMC X12

• Bottom Bracket
Sealed Outboard Bearing

• Brakes
Shimano MT201 / UR300 Flat Mount Hydraulic Disc Brakes, 160mm Rotors

• Brake Levers
Shimano Hydraulic

• Wheelset
Marin Aluminum Double Wall Rims, 21mm Inner Width

• Front Hub
Forged Aluminum, 100x12mm, 32H

• Rear Hub
Shimano Forged Aluminum, 142x12mm, Microspline, 32H

• Tires
WTB Riddler 700x45c

• Handlebar
Marin MiniRiser

• Stem
Marin 3D Forged Alloy

• Grips
Marin MTB

• Seatpost
Marin Alloy

• Saddle
Marin DSX Saddle

• Pedals
Commute Platform Pedals

• Headset
FSA No.42 ACB Sealed Cartridge Bearings, 1 1/8” x 1 1/2”

• Color Options
Gloss Black / Grey (#1E1E1E)

Geometry

Built for riders seeking a versatile flat bar adventure bike capable of commuting, gravel exploration, fitness riding, and mixed-terrain adventures.
