FSA | Energy Super Compact ACR Handlebar

Compact control, clean routing, and high-strength alloy construction.

The FSA Energy Super Compact ACR is an aluminum road handlebar designed for riders who prefer a shorter reach, shallower drop, and less aggressive riding position.

Its double-butted and tapered AL7050 construction varies the tubing thickness and diameter to balance strength, stiffness, and weight. The ergonomic flattened tops create a comfortable hand position, while the wide round center section leaves plenty of room for mounting accessories. Compatibility with FSA’s ACR and SCR systems also supports cleaner integrated or semi-integrated cable routing.

Important Compatibility Note

This handlebar has a 31.8 mm clamp diameter and supports FSA ACR and SCR cable routing systems. Proper routing depends on the stem, headset, frame, and drivetrain components used. Not sure if it will work with your setup? Feel free to message us, and we’ll help you confirm compatibility before ordering.

Key Features

• Super Compact Geometry
The 80 mm reach and 125 mm drop create a more accessible riding position with easier transitions between the tops, hoods, and drops.

• ACR and SCR Compatibility
Supports FSA Aerodynamic Integrated Cable Routing and Semi-integrated Cable Routing systems for a cleaner cockpit.

• AL7050 Alloy Construction
Double-butted and tapered aluminum tubing places material where strength is needed while reducing unnecessary weight.

• Ergonomic Flat Tops
A 34 mm flattened upper section provides a broader and more comfortable hand position.

• Accessory-Friendly Center Section
The 110 mm-wide round center section provides space for mounting lights, computers, and other cockpit accessories.

• Four-Degree Outward Bend
A subtle outward bend gives the rider additional control and wrist clearance when using the drops.

Technical Specifications

• Category
Road Handlebar

• Discipline
Road

• Material
Double-butted and tapered AL7050 aluminum

• Shape
Super Compact

• Width Options
360, 380, 400, 420, and 440 mm

• Clamp Diameter
31.8 mm

• Reach
80 mm

• Drop
125 mm

• Outward Bend
4°

• Flat Top Width
34 mm

• Round Center Section
110 mm wide

• Cable Routing Compatibility
FSA ACR and SCR

• Finish
Bead-blasted black with polished black anodized sections

• Weight
285 g

• Included Components
Handlebar only

An adaptable compact bar for greater comfort, confident control, and a cleaner road cockpit.
